Kompressor Bitzer 4FES-5Y-40S
Kompressor Bitzer 4FES-5Y-40S - Image 2
Kompressor Bitzer 4FES-5Y-40S - Image 3
Kompressor Bitzer 4FES-5Y-40S - Image 4

Kompressor Bitzer 4FES-5Y-40S

Kategooria:

Kirjeldus

  • Stroke volume: 18.05 m³/h
  • Oil quantity: 2 dm³
  • Oil type: BSE32
  • DL (I): 5/8 inch, DL (M): 16 mm
  • SL (I): 7/8 inch, SL (M): 22 mm
  • Number of cylinders: 4
  • Weight: 86 kg

Külmavõimsus:

kW at 0ºC/+40ºC 14,8
kW at -5ºC/+40ºC 12,3
kW at -10ºC/+40ºC 10,0
kW at -20ºC/+40ºC 6,5
kW at -30ºC/+40ºC 4,0
kW at -40ºC/+40ºC 2,2

https://maman91.co.il/wp-content/uploads/2019/09/4fes-5y.pdf
